Horizontal Mortar Small Stationary Concrete Pump Diesel Mini Machine

Name: Horizontal Mortar Small Stationary Concrete Pump Diesel Mini Machine
Brand: Hunan Sunny Intelligent Machinery Co.,LTD.
SKU: HBT60
Price: 6,000.00 USD
Availability: InStock

Product Details

Place of Origin: Hunan

Brand Name: Sunny

Model Number: HBT60

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: USD5000-7000 PER SET

Packaging Details: FULL CONTAINER

Delivery Time: 20-35DAYS

Payment Terms: L/C, D/P, T/T, Western Union

Supply Ability: 500 SET PER MONTH

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                horizontal Stationary Concrete Pump, Mini Stationary Concrete Pump, Stationary pump machine concrete


Application:	Concrete Pump,Trailer Pump	Warranty:	3 Years
Model:	HBT60	S Valve:	Yes
Mixer Mode:	JZM350	Power Rating:	110kW
Pump Output:	25 M³/h	Hydraulic Oil Tank Capacity:	600L
Pipe Diameter:	100 Or 125mm	Applicable Industries:	Construction Works
Weight:	8000kg	Wheel Number:	4
Hopper Capacity:	600L	Lubrication System:	Automatic
Max. Aggregate Size:	40mm	Generator Power:	50kw
Max. Theoretical Pressure:	80 Bar	Power Type:	Electric/Diesel

Application:	Concrete Pump,Trailer Pump
Warranty:	3 Years
Model:	HBT60
S Valve:	Yes
Mixer Mode:	JZM350
Power Rating:	110kW
Pump Output:	25 M³/h
Hydraulic Oil Tank Capacity:	600L
Pipe Diameter:	100 Or 125mm
Applicable Industries:	Construction Works
Weight:	8000kg
Wheel Number:	4
Hopper Capacity:	600L
Lubrication System:	Automatic
Max. Aggregate Size:	40mm
Generator Power:	50kw
Max. Theoretical Pressure:	80 Bar
Power Type:	Electric/Diesel

Horizontal Mortar Small Stationary Concrete Pump Diesel Mini Machine

Product Specifications

Attribute	Value
Application	Concrete Pump, Trailer Pump
Warranty	3 years
Model	HBT60
S Valve	Yes
Mixer Mode	JZM350
Power Rating	110kW
Pump Output	25 m³/h
Hydraulic Oil Tank Capacity	600L
Pipe Diameter	100 or 125mm
Applicable Industries	Construction Works
Weight	8000kg
Wheel Number	4
Hopper Capacity	600L
Lubrication System	Automatic
Max. Aggregate Size	40mm
Generator Power	50kw
Max. Theoretical Pressure	80 bar
Power Type	Electric/Diesel

Product Overview

The HBT60 concrete mortar pump is a compact yet powerful construction solution designed for efficient concrete placement in various construction projects.

Key Features

High Efficiency: Delivers 25 m³/h pumping capacity for rapid concrete placement, improving construction productivity.
Versatile Performance: Handles various concrete mixes including low slump, high slump, and lightweight concrete.
Precision Placement: Enables accurate concrete delivery in vertical, horizontal, and overhead applications.
Labor Savings: Reduces manual labor requirements and minimizes material wastage.
Dual Power Option: Available in electric or diesel configurations for flexible operation.
Automatic Lubrication: Ensures smooth operation and reduced maintenance requirements.

Technical Parameters

Parameters	Unit	HBT30.6.35S	HBT40.8.45S	HBT50.10.55S	HBT60.13.90S	HBT80.16.110S
Type of Power Machine	/	Electric/Diesel engine	Electric/Diesel engine	Electric/Diesel engine	Electric/Diesel engine	Electric/Diesel engine
Pumping Volume(Max)	m³/h	30	35	52	66	75
Outlet Pressure	Mpa	6	8	10	13	13
Hydraulic System Type	/	Open	Open	Open	Open	Open
High/Low Switch	/	Rotary Valve	Rotary Valve	Rotary Valve	Rotary Valve	Rotary Valve
Rater Power	kw	35	45	55	90	90
Distribution Valve Type	/	S Valve	S Valve	S Valve	S Valve	S Valve
Concrete Cylinder Diameter*Stroke	mm	Φ125*600	Φ140*1000	Φ200*1000	Φ200*1650	Φ200*1800
Hopper Capacity*Feeding Height	L*mm	350*1000	350*1100	600*1400	600*1400	600*1400
Max.Aggregate Size	mm	Pebble:20; Crushed Stone:20	Pebble:20; Crushed Stone:20	Pebble:50; Crushed Stone:40	Pebble:50; Crushed Stone:40	Pebble:50; Crushed Stone:40
Total Weight	kg	2300	2500	4500	6000	6100
