SANY SY309C Concrete Cement Mixer Truck Lorry 10M3 For Foundation Construction

Product Details

Place of Origin: Hunan

Brand Name: Sany

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: USD10000-30000 PER SET

Delivery Time: 20-35DAYS

Payment Terms: L/C, T/T

Supply Ability: 50 SET PER MONTH

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                Foundation concrete cement mixer truck, 10M3 concrete cement mixer truck, SANY SY309C lorry mixer


Max. Theoretical Output:	60m3/h	Hopper Capacity:	0.6m3
Distribution Valve Type:	S Valve	Power Type:	Diesel
Year Of Manufacture:	2017	Boom Length:	27.5m
Max. Horizontal Conveying Distance:	500m	Chassis Brand:	Isuzu
Max. Theoretical Pumping Pressure:	13Mpa	Max. Vertical Conveying Distance:	150m
Model:	HBT60C-1413D	Chassis Model:	CYH51Y
Max. Aggregate Size:	40mm	Boom Type:	4-section RZ Type

Max. Theoretical Output:	60m3/h
Hopper Capacity:	0.6m3
Distribution Valve Type:	S Valve
Power Type:	Diesel
Year Of Manufacture:	2017
Boom Length:	27.5m
Max. Horizontal Conveying Distance:	500m
Chassis Brand:	Isuzu
Max. Theoretical Pumping Pressure:	13Mpa
Max. Vertical Conveying Distance:	150m
Model:	HBT60C-1413D
Chassis Model:	CYH51Y
Max. Aggregate Size:	40mm
Boom Type:	4-section RZ Type

SANY SY309C Concrete Cement Mixer Truck Lorry 10M3 For Foundation Construction

Product Specifications

Attribute	Value
Max. Theoretical Output	60m3/h
Hopper Capacity	0.6m3
Distribution Valve Type	S Valve
Power Type	Diesel
Year Of Manufacture	2017
Boom Length	27.5m
Max. Horizontal Conveying Distance	500m
Chassis Brand	Isuzu
Max. Theoretical Pumping Pressure	13Mpa
Max. Vertical Conveying Distance	150m
Model	HBT60C-1413D
Chassis Model	CYH51Y
Max. Aggregate Size	40mm
Boom Type	4-section RZ type

Product Features

Robust Construction & Superior Visibility

Framework structure with robot-welded body meets strict collision and pressure regulations for reliable quality. Superior instrument panel and rearview mirror design eliminates blind spots for all-direction visibility in various working conditions.

Advanced Safety Braking System

Utilizes engine auxiliary power braking with joint brake operation, increasing braking distance by 15% while reducing brake lining wear by 50%. Large-power air compressor and high-quality pipeline with new sealing technology ensure quick brake response.

Energy Efficient Operation

Dual-power engine model adapts to full load and no load conditions. Unique economic transmission portfolio reduces fuel consumption by 10% through optimized mixer truck matching technology.

Low Deck Design

Industry-first "No Sub-frame Structure" lowers deck height by 140mm to 200mm. Optimized frame structure from years of R&D ensures stable operation.

Enhanced Maneuverability

Large-displacement power steering oil pump reduces operating force by 40%. Optimized chassis pipeline and front axle steering angle decreases turning diameter by 15% for superior flexibility.

Anti-Buildup Technology

Three-section folded blade increases discharge glide angle. Innovative flushing device and connecting structures prevent aggregate buildup at critical points, reducing residual discharge rate to just 0.4%.

Smart Monitoring System

Integrated GPS provides real-time monitoring of location, oil level, and discharge with five key functions: mixer truck monitoring, record playback, event alarm, management, and statistical analysis.
