Compact Fixed RCC Concrete Asphalt Bitumen Batch Mix Plant Machine

Name: Compact Fixed RCC Concrete Asphalt Bitumen Batch Mix Plant Machine
Brand: Hunan Sunny Intelligent Machinery Co.,LTD.
SKU: LB1500
Price: 150.00 USD
Availability: InStock

Product Details

Place of Origin: Hunan

Brand Name: Sunny

Model Number: LB1500

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: USD250,000-50,0000 PER SET

Packaging Details: FULL CONTAINER

Delivery Time: 20-35DAYS

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 50 SET PER MONTH

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                RCC bitumen batch mix plant, Concrete bitumen batch mix plant, RCC asphalt concrete plant


Warranty:	1 Year	After-sales Service Provided:	Engineers Available To Service Machinery Overseas
Type:	Asphalt Mixing Plant	Application:	High-grade Asphalt Road Paving,Construction Areas,Road Construction Asphalt Plant
Control System:	PLC+colorized Touching Screen

Warranty:	1 Year
After-sales Service Provided:	Engineers Available To Service Machinery Overseas
Type:	Asphalt Mixing Plant
Application:	High-grade Asphalt Road Paving,Construction Areas,Road Construction Asphalt Plant
Control System:	PLC+colorized Touching Screen

Compact Fixed RCC Concrete Asphalt Bitumen Batch Mix Plant Machine

Product Specifications

Model	Rated Output	Mixer Capacity	Dust removal effect	Total power	Fuel consumption	Fire coal	Weighing accuracy	Hopper Capacity	Dryer Size
LB1000	80t/h	1000kg	≤20 mg/Nm³	264kw	5.5-7 kg/t	10kg/t	aggregate;±5‰ powder;±2.5‰ asphalt;±2.5‰	4×8.5m³	φ1.75m×7m
LB1300	100t/h	1300kg	264kw	4×8.5m³	φ1.75m×7m
LB1500	120t/h	1500kg	325kw	4×8.5m³	φ1.75m×7m
LB2000	160t/h	2000kg	483kw	5×12m³	φ1.75m×7m

Key Features

Optimal Production Capacity: The LB1500 model delivers 120 tons per hour, ideal for medium to large-scale asphalt production projects.
Efficient Mixing System: Twin-shaft paddle mixer ensures uniform blending of aggregates, filler, and bitumen for consistent, high-quality asphalt.
Precision Control: Advanced weighing systems and PLC+touch screen controls enable accurate material dosing and temperature adjustments.

Product Attributes

Warranty	1 Year
After-sales service	Engineers available for overseas machinery servicing
Type	Asphalt mixing plant
Application	High-grade asphalt road paving, construction areas, road construction projects
Control system	PLC with color touch screen interface
