Stationary Central Bitumen Production Asphalt Mixing Plant 120TPH Touchscreen

Name: Stationary Central Bitumen Production Asphalt Mixing Plant 120TPH Touchscreen
Brand: Hunan Sunny Intelligent Machinery Co.,LTD.
SKU: LB1000
Price: 150.00 USD
Availability: InStock

Product Details

Place of Origin: Hunan

Brand Name: Sunny

Model Number: LB1000

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: USD250,000-50,0000 PER SET

Packaging Details: FULL CONTAINER

Delivery Time: 20-35DAYS

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 50 SET PER MONTH

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                Bitumen Production Asphalt Mixing Plant, Touchscreen Asphalt Mixing Plant, 120TPH stationary asphalt plant


Warranty:	1 Year	After-sales Service Provided:	Engineers Available To Service Machinery Overseas
Type:	Asphalt Mixing Plant	Application:	High-grade Asphalt Road Paving,Construction Areas,Road Construction Asphalt Plant
Control System:	PLC+colorized Touching Screen

Warranty:	1 Year
After-sales Service Provided:	Engineers Available To Service Machinery Overseas
Type:	Asphalt Mixing Plant
Application:	High-grade Asphalt Road Paving,Construction Areas,Road Construction Asphalt Plant
Control System:	PLC+colorized Touching Screen

Stationary Central Bitumen Production Asphalt Mixing Plant 120TPH Touchscreen

Product Overview

The LB1500 asphalt plant incorporates advanced technology for precise measurement and control. Equipped with a highly accurate weighing system, it ensures precise dosing of aggregates, filler, and bitumen. The PLC control system with color touchscreen allows for flexible adjustment of mixing ratios and temperature settings to produce various asphalt mix designs.

Key Specifications

Attribute	Value
Warranty	1 Year
After-sales service	Engineers available to service machinery overseas
Type	Asphalt mixing plant
Application	High-grade Asphalt Road Paving, Construction Areas, Road Construction
Control system	PLC + Color Touch Screen

Key Features

Energy Efficiency: Advanced dust collection systems ensure ≤20 mg/Nm³ emissions, complying with environmental regulations while reducing energy consumption.
User-Friendly Operation: Intuitive touchscreen interface and well-organized layout enable efficient monitoring and control of production processes.
Customization Options: Flexible configuration allows adaptation to specific project requirements and diverse production needs.
Durable Construction: High-quality materials ensure reliable performance in demanding environments with long service life.

Technical Specifications

Model	Rated Output	Mixer Capacity	Dust Removal	Total Power	Fuel Consumption	Weighing Accuracy
LB1000	80t/h	1000kg	≤20 mg/Nm³	264kw	5.5-7 kg/t	Aggregate: ±5‰ Powder: ±2.5‰ Asphalt: ±2.5‰
LB1500	120t/h	1500kg	≤20 mg/Nm³	325kw	5.5-7 kg/t	Aggregate: ±5‰ Powder: ±2.5‰ Asphalt: ±2.5‰
LB2000	160t/h	2000kg	≤20 mg/Nm³	483kw	5.5-7 kg/t	Aggregate: ±5‰ Powder: ±2.5‰ Asphalt: ±2.5‰

Product Images

Note: All specifications are subject to change without prior notice. Contact our engineering team for customized solutions tailored to your specific project requirements.
