Stationary Continuous Asphalt Mixing Plant Hot Mix Batching Plant OEM

Name: Stationary Continuous Asphalt Mixing Plant Hot Mix Batching Plant OEM
Brand: Hunan Sunny Intelligent Machinery Co.,LTD.
SKU: LB2000
Price: 150.00 USD
Availability: InStock

Product Details

Place of Origin: Hunan

Brand Name: Sunny

Model Number: LB2000

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: USD250,000-50,0000 PER SET

Packaging Details: FULL CONTAINER

Delivery Time: 20-35DAYS

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 50 SET PER MONTH

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                Stationary continuous asphalt mixing plant, OEM continuous asphalt mixing plant, Continuous hot mix batching plant


Warranty:	1 Year	After-sales Service Provided:	Engineers Available To Service Machinery Overseas
Type:	Asphalt Mixing Plant	Application:	High-grade Asphalt Road Paving,Construction Areas,Road Construction Asphalt Plant
Control System:	PLC+colorized Touching Screen

Warranty:	1 Year
After-sales Service Provided:	Engineers Available To Service Machinery Overseas
Type:	Asphalt Mixing Plant
Application:	High-grade Asphalt Road Paving,Construction Areas,Road Construction Asphalt Plant
Control System:	PLC+colorized Touching Screen

Stationary Continuous Asphalt Mixing Plant Hot Mix Batching Plant OEM

Product Overview

The LB2000 is a 160T/H environmentally-friendly stationary batch mix asphalt plant designed for large-scale asphalt production. Part of the renowned LB series, this model combines advanced technology with superior performance for demanding construction projects.

Key Specifications

Attribute	Value
Warranty	1 Year
After-sales service	Engineers available to service machinery overseas
Type	Asphalt mixing plant
Application	High-grade asphalt road paving, construction areas, road construction
Control system	PLC + colorized touching screen

Product Features

Modular design with integrity steel base for easier transportation and installation
Advanced drying drum plate design with proprietary combustion heating technology for improved efficiency and reduced energy consumption
High-capacity hot aggregate bin design increases storage capacity and production output

Technical Specifications

Model	Rated Output	Mixer Capacity	Dust Removal	Total Power	Fuel Consumption	Weighing Accuracy	Hopper Capacity	Dryer Size
LB1000	80t/h	1000kg	≤20 mg/Nm³	264kw	5.5-7 kg/t	Aggregate: ±5‰ Powder: ±2.5‰ Asphalt: ±2.5‰	4×8.5m³	φ1.75m×7m
LB1300	100t/h	1300kg	≤20 mg/Nm³	264kw	5.5-7 kg/t	Aggregate: ±5‰ Powder: ±2.5‰ Asphalt: ±2.5‰	4×8.5m³	φ1.75m×7m
LB1500	120t/h	1500kg	≤20 mg/Nm³	325kw	5.5-7 kg/t	Aggregate: ±5‰ Powder: ±2.5‰ Asphalt: ±2.5‰	4×8.5m³	φ1.75m×7m
LB2000	160t/h	2000kg	≤20 mg/Nm³	483kw	5.5-7 kg/t	Aggregate: ±5‰ Powder: ±2.5‰ Asphalt: ±2.5‰	5×12m³	φ1.75m×7m
